1 Circuit 2 Channel TCA9517DGKRQ1 Voltage Level Translator Bidirectional 8-VSSOP
Product Description Of TCA9517DGKRQ1
TCA9517DGKRQ1 is a bidirectional buffer with level shifting capabilities for I2C and SMBus systems. It supplies bidirectional voltage-level translation (up-translation and/or down-translation) between low voltages (down to 0.9 V) and higher voltages (2.7 V to 5.25 V) in mixed-mode applications. This device enables I2C and SMBus systems to be extended without loss of performance, even during level shifting.
TCA9517DGKRQ1 buffers both the serial data (SDA) and the serial clock (SCL) signals on the I2C bus, thus allowing two buses of up to 400-pF bus capacitance to be connected in an I2C application.
Specification Of TCA9517DGKRQ1
| Part Number | TCA9517DGKRQ1 |
| Translator Type | |
| Channel Type | |
| Number of Circuits | |
| Channels per Circuit | |
| Voltage - VCCA | |
| Voltage - VCCB | |
| Operating Temperature | |
Features Of TCA9517DGKRQ1
- AEC-Q100 Qualified for automotive applications
- Device temperature: –40°C to 125°C TA
- Device HBM classification Level: ±5500-V
- Device CDM classification Level: ±1000-V
- Two-channel bidirectional buffer
- I2C Bus and SMBus compatible
- Operating Supply Voltage Range of 0.9-V to 5.25-V on A-side
- Operating supply voltage range of 2.7-V to 5.25-V on B-side
- Voltage-level translation from 0.9-V to 5.25-V and 2.7-V to 5.25-V
- Active-high repeater-enable input
- Open-drain I2C I/O
- 5.25-V tolerant I2C and enable input support mixed-mode signal operation
- Accommodates standard mode and fast mode I2C devices and multiple controller
- High-impedance I2C pins when powered-off
- Latch-up performance exceeds 100 mA Per JESD 78, class II
Applications Of TCA9517DGKRQ1
- Servers
- Routers (telecom switching equipment)
- Industrial equipment
- Products with Many I2C targets and/or long PCB traces
Simplified Schematic Of TPS7A8300RGWR
Pin Configurations Of TPS7A8300RGWR
